Tuesday, March 26, 2013

Fabric Dyeing Basics Tutorial

Fabric Dyeing Basics by Jeni Baker
Fabric Dyeing Basics, a photo by Jeni Baker on Flickr.
Over the past couple of years I have really enjoyed experimenting with fabric dyeing.  I've played around with wax-resist dyeing with the aid of Malka Dubrawsky's Color Your Cloth, and have almost exclusively worked with Procion MX cold water dyes.  There are a lot of advantages to this type of dyeing: the colors are pretty true, very vibrant, and even.  There are a lot of disadvantages too.  They are expensive, toxic, and the process takes about 8 hours plus setup and clean up.

A few weeks ago I wanted to see what I could do about finding alternative dyeing and resist techniques to make it more accessible.  It was fun to experiment and see what I could come up with! These techniques use RIT dye, and aren't a true replacement for the other method, but they are a great place to start if you're interested in learning to dye fabric!

RIT Dyed Fabrics
RIT Dyed Fabrics, a photo by Jeni Baker on Flickr.
The advantages of using RIT dye: it's cheap, readily available, less time consuming and safe (see their safety information here).  The disadvantages: It is more difficult to achieve vibrant colors.


Materials
Dyeing Supplies by Jeni Baker
Dyeing Supplies, a photo by Jeni Baker on Flickr.
For this basic dyeing, everything you need can easily be found at your local grocery store and craft store.  While the RIT dye is pretty safe, you'll want to designate these tools for dyeing and no longer use them for food just to be safe. You'll need:

Fabric to dye: For RIT dye you'll want to use 100% cotton fabric.  It can be used to dye synthetic fabrics, but you're going to get better results sticking with natural fibers.  Fabrics that are white-on-white prints look really cool when dyed because for the most part the printing stays white! Pre-wash and dry all fabrics before dyeing. If you're dyeing right after washing you can skip drying.

Liquid RIT dye: The liquid version is easier to use for this process and it can be used multiple times since you won't need much.

Salt: Plain table salt, not iodized.

Soda Ash: This is the dye fixer.  It can be found with the tie-dye supplies and dyes at most craft stores.  It is Sodium Carbonate, and is also used to raise the PH level in pools, so it can sometimes be found with pool supplies in large quantities.

Rubber Gloves: I just use a pair of regular kitchen dish gloves.

Plastic containers: I make my dye baths in big empty yogurt containers, cheap plastic pitchers or plastic dish tubs.

Measuring cups & spoons: I picked up a set of each at the dollar store.

Stirring spoon: A plastic spoon for stirring.


Basic Dyeing Technique
Dye Baths by Jeni Baker
Dye Baths, a photo by Jeni Baker on Flickr.
Okay, now that we have our supplies, let's talk about the basics of dyeing.  The instructions are for a fat quarter, but a table with conversions for other amounts is also provided.  I'd recommend wearing an apron or "craft clothes" in case you spill some dye.  I like to do my dyeing either in a bathtub or sink for easy clean up.

1. Fill your dye bath container with 1 quart of HOT water.

2. Put 2 Tablespoons of salt in the water, stir until dissolved.

3. Carefully measure out 2 Tablespoons Liquid RIT into the salt water, stir.

4. In a separate container, wet fat quarter (or 1/4 yard) of fabric.  Squeeze out excess water.

5. Put fabric in the dye.  Stir constantly for the first 5 minutes or so to ensure even coverage.  Leave in bath for 30 minutes, stirring every 5 minutes..

6. After 30 minutes, carefully remove fabric from dye bath.  Add 1 Tablespoon of Soda Ash to the dye bath. Stir until dissolved.

7. Add fabric back into the dye bath, stirring for a few minutes. Leave in bath for 30 minutes to 1 hour, stirring every 10-15 minutes.

8. Remove fabric from dye bath, dump dye down the drain.

9. Rinse out fabric, starting with cold water, then warm water, then hot water until the water runs clear.

10. Wash normally with detergent on warm/cold.  If I've dyed a dark purple and a light yellow I'll often do two different loads, otherwise I put multiple colors together.  Add 1/2 cup of salt to the washer (in water for top loading, with detergent for front loading) to help reduce bleeding.  Dry or remove from washer and press with a hot iron.

I calculated these amounts based on previous dyeing experience and the instructions on the RIT bottle.  Fat quarters can be substituted for yardage.

RIT has a Color Formula Tool on their website that helps you create up to 500 different colors by mixing different RIT dyes.  Personally, I like to just wing it, but it would be a great place to start if you have a certain color in mind.

Double Dye Amount by Jeni Baker
Double Dye Amount, a photo by Jeni Baker on Flickr.
Doubling the dye amounts (as recommended by RIT for bright colors) Made a pretty noticeable difference for this pink color.

Cherry Red RIT by Jeni Baker
Cherry Red RIT, a photo by Jeni Baker on Flickr.
Doubling the dye amounts did not make a noticeable difference when I was trying to achieve a true red (I used Cherry Red). You'll have to experiment a bit too!

Alternative Resist Methods
Hand-Dyed by Jeni Baker
Hand-Dyed using Wax Resist, a photo by Jeni Baker on Flickr.
The most common dye resist method uses wax, which is the same process that is used to create Batik fabrics.  Wax is applied to the fabric before dyeing, and the wax keeps that portion of the fabric un-dyed.  Using wax creates beautiful results (shown in the image above), but it is messy and can be difficult to remove after the dyeing process.  I experimented with a couple of other methods to see if I could get similar results.

For all of these methods I applied the resist to dry fabric before dyeing.  Let the resist dry if need be and then dye with the instructions outlined in the beginning of this post.

Alternative Resist Methods by Jeni Baker
Alternative Resist Methods, a photo by Jeni Baker on Flickr.
1. Hot Glue:  This was a long shot! In a few places it worked okay, but for the most part it did not stick well to the fabric and started to come off as soon as it hit the water. It's too bad it didn't work, it was very easy to apply and dried very quickly.

2. Crayons:  I am wondering how much wax is in traditional crayons, because this was the worst method I tried.  I used a white crayon to draw on the fabric and it's barely even visible.  I wanted to try these wax-resist sticks but couldn't find them locally.  They may be worth a try, but traditional crayons are not!

3. Elmer's School Glue Gel: This by far worked the best of the three methods I tried.  It was pretty consistent and the results are pretty similar to what you can achieve with wax.  I applied it pretty thickly onto the fabric, which took most of the day to dry.  I'd recommend applying it and letting it dry overnight.  It worked well being squeezed onto the fabric and dipping a tool into it and stamping.  This is a great resist to try!

Elmer's Blue Gel Glue by Jeni Baker
Elmer's Blue Gel Glue, a photo by Jeni Baker on Flickr.
Both fabrics shown above were creating using Elmer's School Glue Gel.  For the Purple fabric I squeezed the glue straight onto the fabric, creating a shape with simple lines.  For the orange fabric, I poured glue into a small dish and dipped a cardboard toilet paper roll into it and stamped it onto the fabric, twisting it a bit on the fabric to get more glue onto it.  Both methods provided great results!

Don't hang it up to dry unless you want drip marks! Dry flat.

RIT Dyed Fabrics by Jeni Baker
RIT Dyed Fabrics, a photo by Jeni Baker on Flickr.
There are a few more techniques I'd like to try with this type of dyeing as well as the with the cold water dyes this summer.  I'll be sure to do an update if they're successful!

For these fabrics I used the following dyes (purple, green, and orange were made by mixing): Cherry Red, Fuchsia, Petal Pink, Lemon Yellow, Aquamarine, and Teal.

Hand-Dyed Fabrics Update by Jeni Baker
Hand-Dyed Fabrics Update, a photo by Jeni Baker on Flickr.
I hope that this post was helpful! I know that dyeing can be scary but it's really a lot of fun! If you're interested in using Procion MX dyes or wax-resist dyeing, I highly recommend Malka Dubrawsky's Color Your Cloth! All of the fabrics in the above image were dyed using Procion MX cold water dyes!

Please note, I am not an expert when it comes to dyeing.  I have learned some tricks and tips while experimenting on my own, but please exercise caution when working with dyes.  Keep small children and pets away from dye baths and supplies.  Dye is permanent and will stain clothes and tile grout.  It will temporarily stain bathtubs, but can easily be cleaned up with bleach-based cleaning products. Use your best judgement and consult the RIT website for more information on their dyes.

Happy Dyeing!
